RES-5011

Standard functions:

Automatic zero calibration (AUTOCAL)

Automatic optimization (AUTOTUNE)

Automatic phase angle compensation (AUTOCOMP)

Automatic frequency adjustment

Automatic configuration of the secondary voltage and current ranges (AUTORANGE)

TCR Calculator (as from firmware version 310)

Micro-USB interface for ROPEXvisual®

Important features:

EtherNet/IP interface for controlling all controller functions (2 x RJ-45)

Wide voltage range for the use of 110…480 VAC

Eight channels for administration of various calibration values

Booster output

Electrically isolated 0…10 VDC analog output for actual temperature

Heat sealing band alloy and temperature range (max. 500 °C) selectable

Alarm output and indication (LED) with error diagnostics

UL certification
